Pre-Insulated Pipe Making Machine HDPE Jacket Pipe Extrusion Machine/Plastic pipe machine Isolated heat layer and anti-c

Send your inquiry

DESCRIPTION

Basic Info.
Model NO. IPTI-1200
Assembly Structure Integral Type Extruder
Screw Single-Screw
Engagement System Full Intermeshing
Screw Channel Structure Deep Screw
Exhaust Don′t Exhaust
Automation Automatic
Computerized Computerized
Transport Package PE Film
Specification 300-1400MM
Trademark Interplast Machinery
Origin Qingdao
HS Code 84772090
Production Capacity 3 Sets Per Month
Product Description
Pre-Insulated Pipe Making Machine HDPE Jacket Pipe Extrusion Machine/Plastic pipe machine
Isolated heat layer and anti-corrosion layer are wrapped on steel pipe at the same time, continuous production, high efficiency and low cost;
In-line ball blast and de-rust, in-line painting and antirust treatment;
In line complete automatic hydraulic deviation revising machine, high precision, stable and reliable
Multi-roller pressing transmission to convey steel pipe stability;
Large production range:75-1400mm.
The spiral type insulation HDPE jacket machine can be manufactured maximum to 2000mm;

1, Sprial Jacket Insulation Pipe Application (3-6mm thickness)

Pre-Insulated Pipe Making Machine HDPE Jacket Pipe Extrusion Machine/Plastic Pipe Machine

Pre-Insulated Pipe Making Machine HDPE Jacket Pipe Extrusion Machine/Plastic Pipe Machine

Pre-Insulated Pipe Making Machine HDPE Jacket Pipe Extrusion Machine/Plastic Pipe Machine


2, Straight/Plain HDPE Jacket Insulation Pipe Application
Parameters:
ExtruderHaul-off machineDiePipe range
SJ-90SJGF-400-4 clawsΦ110-Φ250Φ75-Φ400
SJ-120SJGF-800-6 lawsΦ420Φ400-Φ760
SJ150SJGF-1500-8 clawsΦ760Φ600-Φ1400

Pre-Insulated Pipe Making Machine HDPE Jacket Pipe Extrusion Machine/Plastic Pipe Machine

Pre-Insulated Pipe Making Machine HDPE Jacket Pipe Extrusion Machine/Plastic Pipe Machine


3, Foaming and Insulation Process for above
The foam platform has two different type: Non-bracket type, with-bracket type(need spacer)
Foam machine adopt high pressure foaming machine; Injection high efficient.
